Overview
This 4MP indoor/outdoor, IP based dome camera provides a sharp, high definition images in daylight or nighttime settings. The camera is available in 2.8mm fixed lens which delivers a 105.3 ° horizontal field of view . Its maximum resolution is 2688*1520 at 25fps and supports Ultra 265 video compression technology, which assures savings in bandwidth and storage. The camera is IP based with integrated PoE technology which makes for a quick and easy installation over a single CAT5e/CAT6 cable. Its housing is IK10 vandal-resistant and IP67 rated for outdoor use, and has 98 feet of night vision using an IR cut filter and IR LEDs.
 |
Features
- High quality image with 4MP, 1/3″CMOS sensor
- 4MP (2688*1520)@ 25fps; 4MP (2560*1440)@ 25fps; 3MP (2304*1296) @30fps; 2MP (1920*1080) @30fps;
- Ultra 265, H.265, H.264, MJPEG
- Easystar technology ensures high image quality in low illumination environment
- 120dB true WDR technology enables clear image in strong light scene
- Smart IR, up to 30m (98ft) IR distance
- Supports 256Gb Micro SD card
- IK10 vandal resistant
- IP67 protection
- Support PoE power supply
- 3-Axis
|
|
|
Application
The typical application for most security cameras networks is to connect the IP cameras to a NVR/DVR for simplified playback and additional storage space. Alternatively you can use an IP cameras as a standalone camera and not part of a network by connecting it directly to a POE switch and save the recording on a micro SD card.
NVR Setup
Specifications
|
Camera
|
| Image Sensor |
1/3″ (4 MP) progressive scan CMOS |
| Minimum Illumination |
Colour: 0.005Lux ( F1.6, AGC ON)
0Lux with IR
|
| Day /Night |
IR cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle |
Pan: 0° to 360°, Tilt: 0° to 68°, Rotate: 0° to 360° |
| S/N |
>52dB
|
| WDR |
120dB |
|
Lens
|
| Lens Type |
2.8mm @F1.6, Fixed-focal |
| Angle of View (H) |
105.3° |
| Angle of View (V) |
57° |
| Angle of View (O) |
136.9° |
|
DORI
|
| DORI Distance |
2.8mm Lens, 63.0m Detect, 25.2m Observe, 12.6m Recognize, 6.3m Identify
|
|
IR
|
| IR Range |
Up to 30m (98ft) |
| Wavelength |
850 nm |
| IR On/Off Control |
Auto/Manual |
|
Video
|
| Video Compression |
Ultra 265, H.265, H.264, MJPEG
|
| H.264 Code Profile |
Baseline profile, Main profile, High profile |
| Frame Rate |
Main Stream: 4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps;
Sub Stream: 720P (1280*720), Max 25fps
|
| Video Bit Rate |
128 Kbps~16 Mbps
|
| OSD |
Up to 4 OSDs |
| Privacy Mask |
Up to 4 areas |
| ROI |
Up to 4 areas |
| Motion Detection |
Up to 4 areas |
|
|
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
|
| Digital Noise Reduction |
2D/3D DNR
|
| Smart IR |
Support |
| Flip |
Normal/Vertical/Horizontal/180°
|
| Dewarping |
Support |
| HLC |
Supported |
| BLC |
Supported |
| Defog |
Digital Defog |
|
Storage
|
| Edge Storage |
Micro SD, up to 256GB
|
| Network Storage |
ANR |
|
Network
|
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL
|
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
| Client |
Phantom CamStation
Phantom CamView |
| Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|
Interface
|
| Network |
1 * RJ45 10M/100M Base-TX Ethernet
|
|
Certification
|
| EMC |
FCC: FCC Part 15
|
| Safety |
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
|
| NDAA Compliant |
Yes |
|
General
|
| Operating Conditions |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
|
| Power |
DC 12V±25%,
PoE (IEEE 802.3af)
Power consumption: Max 3.5W
|
| Surge Protection |
2KV |
| Vandal Resistant |
IK10 |
| Ingress Protection |
IP67 |
| Material |
Shield：PC
Body：plastic
Bottom plate：metal
|
| Dimensions (Ø x H) |
Φ109 x 81mm (Ø4.3” x 3.2”)
|
| Weight |
1.08 lbs [0.49kg] |
